AND Model MCT Series

Attribute:

Table Top Universal Testing Machine MCT Series (Force Tester)

Categories : Tensile Machine

 The MCT series of table top universal testing machines are great alternatives to force and push pull gauges
   Color touch panel - Precise and easy to use
   Two models available: The general purpose MCT-1150 and the rigid and durable MCT-2150 with high precision ball screw and thicker crosshead.
- Color touch panel for clear visibility and simple operation
- High-precision load cell included; just plug in for quick use
- Easy-to-use digital testing-speed settings
- Displacement display included standard
- Includes data capture software for PCs
- Use with your favorite force gage and push-pull gage jigs                (attachments)
- Specifications call for M6 screws. Use M6 male screw thread adapter     when necessary
- Print maximum load and displacement with the AD-8126 mini          printer (sold separately)
- Table top space-saving design 250(W) X 405(D) X 711(H)mm

ModelMCT-1150MCT-2150
Table / floor modelTable model
Maximum capacity500N
Crosshead stroke400mm370mm
Effective stroke315mm285mm
Crosshead speed10-300mm/min: Within5% of the set value
Crosshead speed settingDigital setting: 1mm/min increments within the above range
Crosshead speed
and load capacity
Full speed range at maximum capacity
Crosshead return speedThree speed settings: 10, 100, 300mm/min
Load measurement accuracy±0.2% F.S500N to 50N: ±0.2% F.S
50N to 5N: Within 2% of indicator value
5N and lower: Within 0.1N
Load display resolution0.1N0.01N(0.1N will display for values over 100N)
Load calibration Auto-zero function (calibration unnecessary)
Displacement display000.0mm(Min. 0.1 mm)00.00mm (Min 0.1mm: 0.1mm will display for value over 100mm)
Included softwareMSAT-Lite, MCT-Logger
Safety mechanisms1. Upper and lower displacement stroke limits
2. Overload linit (automatic shutdown when load cell passes 105% of rate capacity
3. Emergency stop switch
Dimensions (W x D x H)250 x 405 x 711mm
Weight17kg18kg
Power SupplyAC90 to 240V 1Ø 50/60Hz
Power consumption90W
Operating ambient condition Temperature: 5 to 40°C Humidity: 20 to 80%RH
Recommended ambient
conditions
 Temperature: 23 ±2°C Humidity: 50 ±10%RH
Standard equipment Instruction manual, 500N capacity load cell, computer software (CD-ROM), USB cable

Data capture software included

MCT-Logger [Recording soft ware]          MSAT-Lite[Data processing software]



Use for a variety of material testing (Caution: The MCT series is not waterproof)

Measuring strength required       Packaging heat seal strength test          Plastic bottle buckling strength test
to press a button



Food packaging film                 Testing push strength for removing        Syringe resistance test
puncture test                         medicine from PTP packaging



Flexible cable pull out test         Tablet strength test                           Food container metal fastener strength test



Bending strength test               Container film opening force test                       Safety cover
