DIGIROCK M SERIES ARC VISION

คุณสมบัติสินค้า:

ELECTRONIC SUPERFICIAL ROCKWELL HARDNESS TESTER

ELECTRONIC SUPERFICIAL ROCKWELL HARDNESS TESTER

DIGIROCK M SERIES

Features

  • DigiRock MR2/MS2 analoguegauge resolution is 0.5HR,
    it is useful to improve the reading accura cy tha trnaditional 1HR resolution;
  • DigiRock MR2/MS2 dwell time from 1to 60s can be setup by the “time key” on the panel ,
    it is much convenient than the setup on the manual hardness tester;
  • DigiRock MR2/MS2 force knob adopts the metal material to replace the plastic,
    it largely improves the instrument using-life;
  • DigiRock MR2/MS2 loading, dwell and unloading is buffering by electronic motor automatically,
    doesnt need the operator to handle it , it eliminates the human operation error maximally;
  • DigiRock MR2/MS2 intenter protector is available to improve the using lifetime of indenter.



Applications

  • Rockwell B Scale HRB: Copper alloys, soft steels, aluminum alloys, malleable iron, etc.
  • Rockwell C Scale HRC: Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100.
  • Rockwell A Scale HRA: Cemented carbides, thin steel, and shallow case- hardened steel.



ProductELECTRONIC SUPERFICIAL ROCKWELL HARDNESS TESTERELECTRONIC SUPERFICIAL ROCKWELL HARDNESS TESTER
ModelDigiRock MR2DigiRock Ms2
Rockwell ScalesHRA, HRB, HRCHR15N, HR30N, HR45N, HR15T, HR30T, HR45T
Preliminary Test Force10kgf (98.07N)3Kgf (29.42N)
Test force60Kgf(558.4N), 100Kgf(980.7N), 150Kgf(1471N)15Kgf(147.1N), 30Kgf(294.2N), 45Kgf(441.3N)
Hardness IndicationAnalogue Display
Dwell timeAdjustable 1~60 sec
Resolution0.5 HR
Loading ControlElectronic
Max. Height of Specimen175 mm
Instrument Throat165 mm
Dimension (LxWxH)  546 x 182 x 755 mm
Packing Dimension620 x 460 x 870 mm
Gross / Net Weight120 Kgf / 90 Kgf
Execution StandardGB/T230.2, JIS Z2245, EN-ISO 6508, ASTM E-18
